Music Factory

(pedal de bombo não incluído)

Reproduz de forma fiel os sons e os ambientes gravados em estúdios de renome mundial
Os botões "Kit Modifier" de AMBIENCE, COMP, e EFFECT permitem criar sons personalizados
Os pads em TCS (exclusivos da Yamaha) asseguram uma sensação natural de toque e ressalto
Pads de 3-zonas para a tarola, crash e ride. Os pratos podem ser abafados e silenciados. O prato Ride vem equipado a função de deteção de posição
Inclui um tripé de prato de choques e um suporte de tarola de bola, original da Yamaha

Módulo		DTX-PRO
Pad	Tarola	XP80 (8") pad TCS de tarola/timbalão com 3 zonas
	Timbalões 1, 2	XP70 (7") pad TCS de timbalão com 1 zona
	Timbalão de chão	XP70 (7") pad TCS de timbalão com 1 zona
	Bombo	KP90 (7.5") pad de borracha com vários níveis de suspensão
	Prato de choques	RHH135 (13") pad de prato com 2 zonas
	Prato de crash 1	PCY135 (13") pad de prato com 3 zonas
	Prato de crash 2	PCY135 (13") pad de prato com 3 zonas
	Prato de ride	PCY135 (13") pad de prato com 3 zonas
	Tripé de prato de choques	HS650A
	Sistema de rack	RS6

SPECS

Pad sets
Snare	XP80 (8 inch TCS pad with 3 zone)	XP80 (8 inch TCS pad with 3 zone)
Tom Pad	XP70 (7 inch TCS pad)	TP70 (7 inch rubber pad)
Floor Tom Pad	XP70 (7 inch TCS pad)	TP70 (7 inch rubber pad)
Kick Pad	KP90 (7.5 inch rubber pad with Multi layer cushion)	KP65 (5 inch rubber pad, double foot pedal compatible)
Hi-hat Pad	RHH135 (13 inch pad with 2 zone)	10 inch pad and HH65 Hi-hat controller
Crash cymbal 1	PCY135 (13 inch pad with 3 zone)	10-inch pad with Choke ability
Crash cymbal 2	PCY135 (13 inch pad with 3 zone)	-
Ride cymbal	PCY135 (13 inch pad with 3 zone)	PCY135 (13 inch pad with 3 zones)
Hi-hat Stand	HS650A	-
Footprint (average)	1,100 mm x 1,400 mm	1,000 mm x 1,100 mm
Weight	36.6 kg	25.2 kg

Tone generator
Dimensions	Width	303 mm (11-15/16 in)
	Height	196 mm (7-11/16 in)
	Depth	66 mm(2-5/8 in)
Weight		1.5 kg (3 lb 5 oz)
Maximum Polyphony		256 notes
Effects		For each Inst: EQ / Comp / Transient / Insertion (1), For each Kit: Ambience / Effect 1 / Effect 2 and Master Comp / Master Effect, For overall: Master EQ / Phones EQ (1) Insertion effects can be used only for specific Inst.
Drum kits		Preset: 40 Kits, User: 200 Kits
Voices		712
Click
Click Sets		30
Tempo		30 to 300 BPM, Tap Tempo supported.
Time signatures		1/4 to 16/4, 1/8 to 16/8, and 1/16 to 16/16
Subdivisions		Accents, quarter notes, eighth notes, sixteenth notes, and eight-note triplets
Others		Individual click volume control, wav import, timer
Training
Types		10
Songs		Preset: 37 songs, User: 1 song
Audio Files
Import limit		1,000 files
Maximum loadable sample time		760 seconds (44.1 kHz, 16 bit, mono), 380 seconds (44.1 kHz, 16 bit, stereo)
sample format		WAV
Recorder
Recording time	Internal memory	Maximum of 90 seconds
Recording time	USB flash drive	Maximum of 90 minutes per file
Format		Record/playback: WAV (44.1 kHz, 16 bit, stereo)
Other
Connectors	DC IN	DC IN (+12V)
	Headphones	Headphones (standard stereo phone jack x 1)
	AUX IN	AUX IN (stereo mini jack x 1)
	Output	OUTPUT L/MONO, R (standard phone jack, one for each)
	USB	USB TO DEVICE, USB TO HOST
	MIDI	MIDI OUT
	Trigger Input	Trigger inputs 1, 14: (Standard stereo phone, L: Trigger, R: Rim switch / Trigger), 2/3, 4/5, 6/7, 12/13: (Standard stereo phone, L: Trigger, R: Trigger), 8, 9, 10, 11: (Standard stereo phone, L: Trigger, R: Rim switch) *Maximum 14 of pads to be connected (when Y-cable is used)
Display		Full Dot LCD (128×64 dot)
Acessórios		AC adaptor (PA-150 or an equivalent recommended by Yamaha)2, Owner’s Manual, module holder, module holder wing bolts (x 4), Cubase AI Download Information 2 May not be included depending on your area. Check with your Yamaha dealer.
